Oil Filter Paper

Home - Filtration Media - Oil Filter Paper

Oil Filter Paper

Oil filtration media offers continuous performance with reliable stability under harsh conditions and extends the lifespan at the same time.

We are the largest supplier of acrylic resin filter paper in China, with more than 30 years of production experience and filter paper with ISO9001 certification. The parameters are the same, there are different grades of products, we can supply to the needs of customers in different areas, please refer to the parameter table on the website, and leave a message stating your requirements and the units needed, we reply within 24 hours and soonest within 2 minutes.

A complete portfolio of high-performance products

Multi-layer products that can withstand harsh engine temperatures and chemical build-up

Excellent efficiency and dust holding capacity

PRODUCT DESCRIPTION

J8001T-P

PropertyUnitNumerical Range
GrammageG/㎡285-295
Thicknessmm0.8±0.05
Air PermeabilityL/㎡.s90-110
Max. Pore Sizeμm≤50
Average Pore Sizeμm45
Burst StrengthkPa≥450
StiffnessmN.m≥10
Corrugation Depthmm0
Resin Content(Acrylic)
%3-7
Volatility
%3-5


Application: Automotive oil bypass filter

Material: Cellulose fiber, Acrylic resin(Non-cured)

Feature: Thermal Stability

Customization: Available

P8001T-P.pdf


J800T-P

PropertyUnitNumerical Range
GrammageG/㎡255-265
Thicknessmm0.8±0.05
Air PermeabilityL/㎡.s60-80
Max. Pore Sizeμm≤50
Average Pore Sizeμm45
Burst StrengthkPa≥450
StiffnessmN.m≥10
Corrugation Depthmm0
Resin Content(Acrylic)
%3-7
Volatility
%3-5


Application: Automotive oil bypass filter

Material: Cellulose fiber, Acrylic resin(Non-cured)

Feature: Thermal Stability

Customization: Available

P800T-P.pdf

J911-WX

PropertyUnitNumerical Range
GrammageG/㎡145-150
Thicknessmm0.6±0.05
Air PermeabilityL/㎡.s310-330
Max. Pore Sizeμm≤75
Average Pore Sizeμm71
Burst StrengthkPa≥300
StiffnessmN.m≥4.1
Corrugation Depthmm0.4-0.45


Application: Automotive oil filter

Material: Cellulose fiber, Acrylic resin(Non-cured)

Feature: Thermal Stability

Customization: Available

J8491D-WX.pdf

J911-WX

PropertyUnitNumerical Range
GrammageG/㎡200±5
Thicknessmm0.6±0.05
Air PermeabilityL/㎡.s350-400
Max.Pore Sizeμm≤78
Average Pore Sizeμm73
Burst StrengthkPa≥400
StiffnessmN.m≥10.0
Corrugation Depthmm0.3-0.35


Application: Automotive oil filter

Material: Cellulose fiber, Acrylic resin(Non-cured)

Feature: Thermal Stability

Customization: Available

J911-WX.pdf

J666-WX

PropertyUnitNumerical Range
GrammageG/㎡140-150
Thicknessmm0.55±0.05
Air PermeabilityL/㎡.s320-380
Max. Pore Sizeμm≤80
Average Pore Sizeμm75
Burst StrengthkPa≥260
StiffnessmN.m≥4.0
Corrugation Depthmm0.3-0.35


Application: Automotive oil filter

Material: Cellulose fiber, Acrylic resin(Non-cured)

Feature: Thermal Stability

Customization: Available

Oil Filter Paper

Oil Filter Paper are one of the key components of an engine system. tianjinsheng is always developing new solutions to improve the performance of oil filtration media.

Oil quality is an important factor in the overall performance and service life of an internal combustion engine, and Tianjinsheng oil filter media protects the engine from contaminants (soot, dust, particles ......), thus maintaining oil quality, reducing engine wear and extending service intervals.


The oil filter media portfolio covers a full range of solutions for automotive and heavy-duty applications that


A cellulose-based platform that meets most aftermarket and OEM requirements

- High synthetic content platform for high durability and improved dust holding capacity requirements

Premium fully synthetic platform providing high levels of performance and durability in hot oils


Tianjinsheng will provide you with oil filter paper solutions

Market leader with global reach

Recognized for the high quality of our products in OEM and aftermarket segments

Complete particle efficiency range with optimum dust holding capacity

Specific impregnation solutions that provide durability even with new generation oils

Longest service intervals and reduced filter size for synthetic oil portfolio


Content that may help you.


What is Oil Filter Paper?

Oil filter paper is used as an oil filter element to protect the engine lubrication system. It can be supplied in rolls, plain or corrugated paper. Available thickness: 0.35 - 0.65mm.


Can filter paper filter oil?

The oil absorption capacity of superhydrophobic filter paper has been evaluated and the results show that the paper can selectively adsorb oil floating on the water surface or in water emulsions. In addition, filtering a mixture of oil and water through the paper can reduce the water content in the oil.


What material is the oil filter made of?

There are three main types of filter media: Cellulose - consists of wood pulp with large fibers and inconsistent pore sizes. Glass fiber (synthetic) - consists of smaller man-made glass fibers with more consistent pore sizes. Composite - consists of a combination of cellulose and glass fiber materials.


What are the two types of oil filters?

Primary oil filter. Most automobile manufacturers use a full-flow filtration system, which contains a primary oil filter, also known as a full-flow filter.

Secondary oil filter. The next major type of oil filter is the secondary oil filter.


Should you pre-install an oil filter?

An age-old question is whether you should pre-fill a new oil filter before installing it into your vehicle. The answer? ... If you have a large heavy truck, pre-filling the filter will make the process easier, but if you are only changing the oil in a smaller vehicle, it is not necessary.


Does the oil filter make any difference?

They look almost the same on the outside, but what's inside can make a big difference. Filter manufacturers use a variety of different filter media to keep oil clean. ... Some filters use a combination of cellulose fibers and non-woven plastic or synthetic fibers to improve filtration efficiency.


Should I change my oil filter every time?

Many manufacturers recommend that you change your oil filter every time you change your oil. So if you are on a 3,000 mile cycle, you would change the filter every 6,000 miles; if you ride 6,000 miles (as with most modern vehicles), you would change it every 12,000 miles.


Can you clean and reuse the oil filter?

Disposable oil filters are not designed to last more than one oil change. Almost all disposable oil filters become clogged before a second change is made. They can only be used once. Reusing a disposable oil filter from a previous oil change can cause significant damage.


Can an old oil filter cause leaks?

When a mechanic may not have installed the filter correctly, keep an eye out for this condition after an oil change. Oil filter leaks can also occur if an incorrect oil filter is used. In this case, the oil filter may not seal properly, which can lead to oil pressure and leakage problems.
